WE ARE SUPPLYING DYNO SHEETS & GRAPHS OF POPULAR ENGINE COMBINATIONS. CONTACT US AT THE SHOP FOR FURTHER INFORMATION AND TO PURCHASE DYNO PROVEN ENGINE COMPONENTS & COMBINATIONS.







THESE DYNO TESTS ARE CONDUCTED ON A STOCK SHORT BLOCK WITH A STOCK GRIND CAMSHAFT. THESE TESTS ARE TO DEMONSTRATE POWER GAINS AVAILABLE WITHOUT GOING INTO THE ENGINE, MODIFICATIONS THAT CAN BE ACCOMPLISHED WITH THE ENGINE IN THE CAR.

STOCK MODEL A FORD ENGINE

STOCK MODEL A FORD ENGINE, "A" CARBURETOR ON BORED OUT "A" MANIFOLD

STOCK MODEL A FORD ENGINE, "B" CARBURETOR ON "A" MANIFOLD

STOCK MODEL A FORD ENGINE, "B" CARBURETOR ON BORED OUT "A" MANIFOLD

STOCK MODEL A FORD ENGINE, WEBER 32/36 CARBURETOR & INTAKE MANIFOLD # A-9510-W

STOCK MODEL A FORD ENGINE, WEBER 32/36 CARBURETOR #A-9510-W & INTAKE MANIFOLD, CAST IRON HEADER # A-9430-H & SMITHYS MUFFLER

STOCK MODEL A FORD ENGINE w "C" HEAD

"C" HEAD, "B" CARBURETOR & A MANIFOLD BORED OUT TO B SIZES
"B" HEAD, B CARBURETOR, A MANIFOLD BORED OUT TO B SIZES

SNYDER HEAD, STOCK ENGINE, A CARB & MANIFOLD

SNYDER HEAD, B CARBURETOR, A MANIFOLD BORED OUT TO B SIZES

SNYDER HEAD, B CARBURETOR, A MANIFOLD BORED OUT TO B SIZES , ARIES MUFFLER

BRUMFIELD HEAD, STOCK ENGINE, A CARB & MANIFOLD

BRUMFIELD HEAD, B CARBURETOR, A MANIFOLD BORED OUT TO B SIZES , ARIES MUFFLER

BRUMFIELD HEAD, DUAL STROMBERG 82 CARBURETORS, BURNS MANIFOLD, ARIES MUFFLER

SCALDED DOG, CHARLIE YAPP'S VORTEX DUAL ZENITH INTAKE MANIFOLD




Dallas Model A Ford Club ENGINE RAFFELED DURING THE 2008 WORLD MEET IN DALLAS, TEXAS 52 HP



THESE DYNO TESTS INVOLVE REMOVING THE ENGINE FROM THE CAR AND MAKING MODIFICATIONS TO THE SHORT BLOCK AS WELL AS THE BOLT ON ITEMS.



RAFFEL ENGINE WITH WEBER CARBURETOR & MANIFOLD, ARIES MUFFLER 63.6 HP

RAFFEL ENGINE WITH WEBER CARBURETOR & MANIFOLD, RED'S 4 TUBE INTO 1 COLLECTOR HEADER & SMITTYS MUFFLER 66.3 HP

RAFFEL ENGINE WITH WEBER CARBURETOR & MANIFOLD, RED'S 4 TUBE INTO 1 COLLECTOR HEADER, OPEN HEADER 73.4 HP

RAFFEL ENGINE WITH WEBER CARBURETOR & MANIFOLD, RED'S 4 TUBE INTO 2 COLLECTOR HEADER, OPEN HEADER 77 HP

OUR STANDARD TOURING ENGINE, A CARB & MANIFOLD, ARIES MUFFLER

TOURING ENGINE, SNYDER HEAD, WEBER CARBURETOR & MANIFOLD, ARIES MUFFLER

74 HORSEPOWER TOURING MODEL A FORD ENGINE

89 HORSEPOWER HIGH PERFORMANCE MODEL A FORD ENGINE

94 HORSEPOWER HIGH PERFORMANCE MODEL A FORD ENGINE

107 HORSEPOWER HIGH PERFORMANCE MODEL A FORD ENGINE

HIGH PERFORMANCE MODEL A FORD ENGINE w STOCK LION 7-1 COMPRESSION HEAD, AS RECIEVED, 93 HORSEPOWER

HIGH PERFORMANCE MODEL A FORD ENGINE w LION 7-1 COMPRESSION HEAD, MODIFIED BY PIRANIO'S ANTIQUE AUTOMOTIVE, 115.5 HORSEPOWER

STREET ROD MODEL A FORD ENGINE w LION 7-1 COMPRESSION HEAD, SPARK PLUG LOCATION TESTS

HIGH PERFORMANCE MODEL A FORD ENGINE w LION 7-1 COMPRESSION HEAD, CUSTOM INTAKE MANIFOLD w WEBER DCOE SIDE DRAFT CARBURETOR, 117.18 HORSEPOWER, 196 FT. LBS. OF TORQUE

DONOVAN MODEL "D" HIGH PERFORMANCE STREET ENGINE, 95 HORSEPOWER


ROOF 101 CYCLONE HEAD STREET ENGINE, 95 HORSEPOWER


RILEY 2 PORT HEAD STREET ENGINE, 83 HORSEPOWER


CRAWFORD HEAD STREET ENGINE,TEST #3, 121 HORSEPOWER


CRAWFORD HEAD STREET ENGINE,TEST #4, 124 HORSEPOWER

PIRANIO'S 2011 BONNEVILLE ENGINE,NATURALLY ASPIRATED GASOLINE FLATHEAD, 138 HORSEPOWER



PIRANIO'S 2012 BONNEVILLE ENGINE,NATURALLY ASPIRATED GASOLINE FLATHEAD, 161 HORSEPOWER




PIRANIO'S 2014 BONNEVILLE ENGINE,NATURALLY ASPIRATED GASOLINE 3 VALVE PER CYLINDER CRAWFORD HEAD, 261.5 HORSEPOWER
